LED Driver | eldoLED SOLOdrive 241/A | 20W | 0-10V

The SOLOdrive LED drivers from eldoLED feature a programmable output (constant current) and offer the ability to dim down to 0.1%. Also easy to apply in combination with single color, dimmable LED fixtures on a 0-10V basis.

Features

• Can be combined with a variety of LED lighting, including single color lighting on 0-10V
• Output current: 150 – 1050 mA
• Output voltage: 2 – 40 volts

Technical data: LED driver | eldoLED SOLOdrive 241/A | 20W | 0-10V

• Input voltage220-240V
• Maximum Power20 Watt
• Output current150-1050 mA
• Output voltage2 – 40 Volt
• DimmableYes
• Protocol0-10V
• Power factor>0.95
• Working temperature-20°C / +50°C
• IP rateIP20
• Length160 mm
• Width41,5 mm
• Height30,5 mm
• Cable lengthN/a
• Connection typeTerminal block
• Housing colorWhite
• Maximum temperature housing80°C
• Certification markCE
• Warranty5 years
