Wall light Sys-Wall68 MiniAMP LED 3W IP44 3000K 120lm 24V

Name: Wall light Sys-Wall68 MiniAMP LED 3W IP44 3000K 120lm 24V
SKU: ISO-114682
Availability: BackOrder

Out of stock status:

7-14 Days

LED recessed wall light Sys-Wall68 MiniAMP 24V, 3W, IP44, 3000K

24,00 €

Price without 24% VAT: 19,35 €

LED recessed wall light Sys-Wall68 MiniAMP 24V, 3W, IP44, 3000K, incl. surface box (excl. cover)

A suitable cover (Art. 114556 to 114568) is required for this light

Dimmable Yes

Product description	LED Recessed wall light Sys-Wall68 MiniAMP 24V, 3W, 3000K, incl. surface box (excl. cover)
GTIN – EAN	9009377085505
Features
Special features	A suitable cover (item 114556 to 114568) is required for this luminaire, wire cross-section 0,5mm²
Nominal voltage	24 V DC
Rated power	3 W
Permissible ambient temp.	-10°C – 35°C
min. ambient temperature in °C	-10
max. ambient temperature in °C	35
Active power	2,5 W
Luminous flux in lumen	120 lm
Efficiency in LM	48
Color temperature	3000K
CRI Ra	90
Beam angle	38°
Beam angle type	fixed
Dimmable	Yes
Dimming type	PWM
Dimming Specifications	Dimmable via voltage sink (not PWM!) e.g. via dimmable LED transformer 24V/D
Protection class	IP44
Housing material	Aluminum
Housing color	white
Weight in gramm	96
Height in mm	54,0
Diameter in mm	79.00 mm
Hole cut-out	59 mm
Hole cutout type	Circle
Installation depth in mm	53
Protection class	2
ext. Transformer length	0.00
ext. Transformer width	0.00
ext. Transformer height	0.00
Lifetime L70\|B10	20000
Useful life L70\|B50	30000
Useful life L80\|B50 in hours	26000
Guarantee in years	2

SKU: ISO-114682 Categories: MINIAMP 24V FAST CONNECT, SYS68-WALL Brand: ISOLED

Data

Recess depth (mm)	53
IP class	IP44
Brands	ISOLED
Input voltage	24V DC
Light Color	3000K
In stock (Vana-Tartu mnt 79A)	No
Dimmable (adj. brightness)	Yes
Light output- Lumens	120 lm
Beam angle	38°
Lifetime L70	20 000hrs
Working temperature	-10° – 35°
Color Rendering Index	CRI>90
Width (mm)	79
Out of Stock Delivery Time From Supplier	7-14 Days
Power consumption/Max power	3W
