DRIVER 48V DC 240W 5A IP65/IP67 0-10V, PWM, Resistance dimming
2-3 Days
Meanwell LED Driver 240Watt Input: 100-240V AC 5A Output: 48V DC 244x71x37.5mm
105,00 €
Price without 24% VAT: 84,68 €
Meanwell LED Driver 240 Watt
LG-240-48 could operate from 100~ 305VAC with the rated voltage 48V. With the high efficiency up to 93%, it is able to work for-40 ℃~ +90 ℃case temperature under free air convection. The aluminium housing design and IP67/IP65 ingress protection level make it possible to meet with both indoor and outdoor applications. In view of its longevity, high efficiency and excellent quality, Meanwell ELG-240-48 is an ideally suitable solution for the optimal design flexibility for LED lighting system
Kind of power supply
LED
Power
240W
Output voltage
48V DC
Output current
5A
IP rating
IP67
Body dimensions
244x71x37.5mm
Manufacturer series
ELG-240
Protection
anti-overload OPP, anti-overvoltage OVP, overheating OTP, short circuit protection SCP
Operating temperature
-40…90°C
Electrical connection
wires L N
Cable length
0.3m
Number of outputs
1
Additional functions
0-10V, PWM, Resistance
https://www.meanwell-web.com/Article/DownloadAsset/ELG-240-spec.pdf?documentId=assets/2057/3eead273bddb410eb896321bb4e2a7e4
Efficiency
93%
Power consumption without load
<0.5W
Operating modes
constant current, constant voltage
- 100…305V AC
- 142…431V DC
- rated parameters obtained at full load
| In stock (Vana-Tartu mnt 79A) | No |
|---|---|
| Out of Stock Delivery Time From Supplier | 2-3 Days |
| Brands | |
| Power consumption/Max power | |
| IP class | |
| Output voltage | |
| Dimmable (adj. brightness) |
