24V LED riba, NEOON LEDRIBAD, Värvilised LED ribad
13x10mm LED NEON RGB 3m 24V 10W/m IP67
Saadavus:
3m roll. Can be cut every 5cm. 13x10mm LED NEON RGB 24V 10W/m IP67
120,00 €
Price without 24% VAT: 96,77 €
3m roll. Can be cut every 5cm.
| Product description | LED NEON RGB flex stripe B13H10 for tile profiles, 24V DC, 10W, 300cm, IP67, 140 LED/m |
|---|---|
| GTIN – EAN | 9009377155826 |
| Features |      |
| Special features | Separation point: 50mm with 7 SMD each | Pitch (light point center-center): 7,14mm | 1 unit (roll) = 3m | max. flex stripe length per infeed: 5m | length tolerance + thermal expansion: 1% | no cooling profile required | without adhesive tape! | silicone encapsulation | Special feature: 30cm 4-pole sheathed cable one-sided, white, connection on side | Note: vertically bendable (bending radius min. 60mm) | Flame retardant and flame resistant (IEC 60695-11-5), IK08 (IEC 62262), salt spray resistant (IEC 60068-2-11:2021), UV resistant (ASTM G154-2016) |
| Nominal voltage | 24V DC |
| Rated power | 10 W/m |
| Active power | 10 W/m |
| RGB light source | Yes |
| Beam angle | 120° |
| Dimmable | Yes |
| Protection class | IP67 |
| Outdoor | YES |
| Permissible ambient temp. | -20°C – 40°C |
| Housing material | Silicone |
| Potting material | Silicone |
| LED chips per metre | 140 |
| LED/roll | 3000 |
| Properties of connection cable | 30cm 2-pin sheathed cable, single-sided, white, side connection, open wire without MiniAmp connector | NOTE: 2x1mm wide and high end caps, vertically bendable (min. bending radius 60mm) |
| Enclosed accessories | Glue |
| Separation point (mm) | 50 mm |
| LED/disconnection point | 7,000000 |
| Pitch SMD (mm) | 7.14 |
| Cooling mass g/m | 0.00 g/m |
| Max. length per feed (m) | 5.00 m |
| Tape type | without adhesive tape |
| Width in mm | 13,0 |
| Length in mm | 3000,0 |
| Height in mm | 10,0 |
| Lifetime L70|B10 | 38000 |
| Useful life L70|B50 | 57000 |
| Useful life L80|B50 in hours | 50000 |
| Guarantee in years | 3 |
