LINEAR 48V seeria, Värvilised LED ribad
30m LED CRI9P Linear 48V 8W IP68 pink 240LED/m
Saadavus:
7-14 päeva
Separation point: 50mm with 12 SMD each | Pitch (chip centre to centre
899,00 €
Price without 24% VAT: 725,00 €
| Product description | LED AQUA CRI9P Linear 48V flex stripe, 8W, IP68, pink, 30m roll, 240 LED/m |
|---|---|
| GTIN – EAN | 9009377074608 |
| Features |       |
| Special features | Separation point: 50mm with 12 SMD each | Pitch (light point center-center): 4,17mm | 1 unit (roll) = 30m | max. flex stripe length per infeed: 30m | length tolerance + thermal expansion: 1% | no cooling profile required | incl. 3M 300LSE adhesive tape | Clean and degrease surface before application! Do not remove again! | silicone encapsulation | Special feature: connection cable on both sides |
| Nominal voltage | 48V DC |
| Rated power | 8 W/m |
| Active power | 8 W/m |
| Efficiency in lm/W | 85 |
| RGB light source | Yes |
| Permissible ambient temp. | -20°C – 45°C |
| max. ambient temperature in °C | 45 |
| min. ambient temperature in °C | -20 |
| CRI Ra | 85 |
| Beam angle | 120° |
| Dimmable | Yes |
| Dimming type | PWM |
| Dimming Specifications | Dimmable via PWM (pulse width modulated DC voltage supply) via upstream controller or dimmable transformer |
| Protection class | IP68 |
| Housing material | Silicone |
| Potting material | Silicon |
| LED chips per metre | 240,000000 |
| LED/roll | 7.200,00 |
| Properties of connection cable | Connection cable on both sides |
| Enclosed accessories | 4 end caps | 40 mounting brackets | adhesive |
| Separation point (mm) | 50.00 mm |
| LED/disconnection point | 12,000000 |
| Pitch SMD (mm) | 4.17 |
| Cooling mass g/m | 0.00 g/m |
| Max. length per feed (m) | 30.00 m |
| Tape type | 3M 300LSE |
| Weight in gramm | 1960 |
| Width in mm | 12,0 |
| Length in mm | 30000,0 |
| Height in mm | 6,0 |
| Lifetime L70|B10 | 53000 |
| Useful life L70|B50 | 80000 |
| Useful life L80|B50 in hours | 70000 |
| Guarantee in years | 2 |
Data
| Kõrgus(mm) | |
|---|---|
| Töötemperatuur | |
| Laos (Peetri, Vana-Tartu mnt 79A) | Ei |
| Pikkus(mm) | |
| LEDide arv x tüüp | |
| Input | |
| Valgusvihu laius | |
| Tööiga L70 | |
| Laius (mm) | |
| Dimmerdatav (hämardatav) | |
| IP klass | |
| Värvieraldusindeks (CRI) | |
| Valguse toon | |
| Light output- Lumens | |
| Bränd | |
| Tarneaeg (kui toode ei ole Eesti laos) | 7-14 päeva |
| Voolutarve/Max W |
